Specifications

Image Sensor

Specifications

• Image Sensor A1/4〞SHARP B 1/3SHARP
• C SONY1/4 D1/3"SONY CCD
• Effective Pixels PAL:512(H)×582（V）　NTSC:512(H)×492(V)
• Horizontal Resolution 420TV lines
• Signal System PAL/NTSC
• Minimum Illumination 0.000Lux×F1.2（LED on）
• LED Φ5 48PCS
• Infraed Lamps 40m
• Backlight Compensation ON
• Shutter Speed 1/50(1/60)-1/100,000sec
• White Balancet Auto
• S/N Ratio More than 48db
• Operation Temperature ～20OC＋60OC　RH95%　Max
• Sync System Internal Synchronization
• Video Output 1.0Vp-p.75Ω
• Power Requirement DC12V±10％1000MA

Specifications

• Image Sensor A1/4〞SHARP B 1/3SHARP
• C SONY1/4 D1/3"SONY CCD
• Effective Pixels PAL:512(H)×582（V）　NTSC:512(H)×492(V)
• Horizontal Resolution 420TV lines
• Signal System PAL/NTSC
• Minimum Illumination 0.000Lux×F1.2（LED on）
• LED Φ5 24PCS
• Infraed Lamps 25m
• Backlight Compensation ON
• Shutter Speed 1/50(1/60)-1/100,000sec
• White Balancet Auto
• S/N Ratio More than 48db
• Operation Temperature ～20OC＋60OC　RH95%　Max
• Sync System 内同步/Internal Synchronization
• Video Output 1.0Vp-p.75Ω
• Power Requirement DC12V±10％1000MA

• Image Sensor A1/4〞SHARP B 1/3SHARP
• C SONY1/4 D1/3"SONY CCD
• Effective Pixels PAL:512(H)×582（V）　NTSC:512(H)×492(V)
• Horizontal Resolution 420TV lines
• Signal System PAL/NTSC
• Minimum Illumination 0.000Lux×F1.2（LED on）
• LED Φ5 48PCS

• Backlight Compensation ON

• Shutter Speed 1/50(1/60)-1/100,000sec

• White Balancet Auto

• S/N Ratio More than 48db

• Sync System 内同步/Internal Synchronization

• Video Output 1.0Vp-p.75Ω

• Power Requirement DC12V±10％1000MA




• Built-in 24 pieces IR-LED
• Effective range up to 20M
• Weatherproofing criterion IP 67
• AC type (option)

Specifications

Picture Elements        NTSC:510x492, PAL:500x582
Resolution                   380 TVL
Min. Illumination           0.2 Lux / F 2.0 (Day), 0 Lux (IR on)
S/N Ratio                     More than 48dB
Electronic Shutter       NTSC:1/60~1/100,000, PAL:1/50~1/110,000
Gamma                       0.45
Lens Furnished           Board Lens 3.6mm / F2.0 (option:4.3/6/8/12/16mm)
White Balance            Auto
Gain Control                Auto
Sync. System              Internal
Video Output               1 Vp-p / 75 Ohms
Infrared Luminary        24 pieces IR-LED
Wavelength                 850 nm
Illuminate Distance     20 M
Waterproofing
Criterion                      IP 67
Power Supply             DC12V±10% (option: AC24V, AC110~240V)
Power Consumption   IR On: 567mA max., IR Off: 125mA max.
Operating Temp.         -10°C ~ 50°C
